C Type Power Press Machine Engineered for Versatility and Precision
Precision C-Frame Power Press, Engineered for Versatility. The C Type Power Press Machine is built for fast metalwork. It handles stamping, punching, and blanking with ease. It gives steady results in every cycle. This C-type power press machine is simple to use and easy to control. It suits modern factories that need speed and accuracy. The machine works well in long shifts. It keeps output stable and smooth.
C Type Power Press Machine - Advanced Industrial Performance
The Trufmac C-Type Mechanical Power Press is made for fast production. It supports metal stamping and cutting work. Its open-back design gives clear 3-sided access. This helps workers load and remove parts quickly. The C Type Power Press Machine improves workflow and saves time. The frame is strong and made from high-quality steel. It is stress-relieving to reduce strain. This lowers deflection during work. The C-Type Power Press Machine gives high accuracy in every stroke. It also increases life. Many industries prefer this machine for daily use in the UAE.
What Makes the C-Type Hydraulic Power Press Manufacturers Different
Open-Gap 3-Sided Access
The open frame gives full access. Large sheets can be handled with ease. Many C Type Hydraulic Power Press Manufacturers focus on this design for better output across the UAE.
Continuous Tonnage Delivery
The system gives a steady force in the full stroke. This is useful for forming work. This feature is common in Hydraulic Power Press C Type systems.
High-Rigidity Steel Frame
The frame is strong and stable. It reduces bending under load. This helps tools last longer.
Precision Ram Guidance
The ram moves in a straight path. It does not shake or twist. This ensures accurate work in a C Frame Hydraulic Press setup.
Adjustable Stroke & Pressure
The operator can set the stroke and pressure. This helps match job needs. It also improves the use of a C Type Hydraulic Power Press.
Advanced Operator Safety
The machine has safety buttons and stop systems. It can also include light safety guards.
Technical Excellence in Hydraulic Power Press C Type Systems
⟵ Scroll horizontally to view full table ⟶
| Top Capacity | Bed Size (L x W) | C-Center | Bed to Ram | Ram Stroke | Stroke Per Minute (25mm) | Bush Hole in Ram | Motor Power | Oil Tank Capacity | Floor to Bed Height | Machine Weight | Wall Thickness | L x W x H (in mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 TON | 300x200 | 100 | 200 | 75 | 65-70 | 25 | 1 HP | 40 LTRS | 500 | 350 KG | 16 MM | 1200x450x600 |
| 10 TON | 430x280 | 140 | 240 | 100 | 75 | 25 | 2 HP | 90 LTRS | 730 | 800 KG | 20 MM | 1950x600x800 |
| 20 TON | 510x304 | 152 | 260 | 125 | 75 | 32 | 3 HP | 140 LTRS | 760 | 1250 KG | 25 MM | 2200x700x850 |
| 30 TON | 585x381 | 190 | 310 | 150 | 75 | 38 | 5 HP | 170 LTRS | 760 | 1550 KG | 25 MM | 2300x800x1100 |
| 40 TON | 610x394 | 197 | 360 | 150 | 65 | 38 | 5 HP | 200 LTRS | 760 | 2000 KG | 25 MM | 2500x800x1200 |
| 50 TON | 686x432 | 216 | 360 | 150 | 60-65 | 50 | 5 HP | 230 LTRS | 760 | 2500 KG | 30 MM | 2650x1000x1400 |
| 80 TON | 762x533 | 266 | 410 | 200 | 60-65 | 50 | 7.5 HP | 320 LTRS | 800 | 3800 KG | 40 MM | 2900x1000x1400 |
| 100 TON | 864x584 | 292 | 460 | 200 | 60-65 | 50 | 10 HP | 320 LTRS | 800 | 5300 KG | 50 MM | 3050x1050x1600 |
| 150 TON | 1016x711 | 355 | 520 | 200 | 60-65 | 80 | 15 HP | 370 LTRS | 800 | 6500 KG | 50 MM | 3050x1050x1600 |
| 200 TON | 1143x864 | 432 | 560 | 200 | 60-65 | 80 | 20 HP | 370 LTRS | 800 | 9200 KG | 60 MM | 3300x1200x1800 |
Industries & Applications of C Type Hydraulic Power Press Machine Suppliers
Sheet Metal Blanking
This process cuts flat shapes from sheets. The frame keeps cuts clean. It also reduces wear. Many C Type Hydraulic Power Press Machine Suppliers support such work.
Piercing & Punching
The machine punches holes with high force. It works well for panels and brackets. This is widely used in factories across the UAE.
Light Bending & Forming
It bends sheets into shapes. This is easy with a C Frame Hydraulic Press. It helps in making brackets and angles.
Fastener & Hardware Production
It is used for washers and clips. High speed helps increase output.
Capacity Range of C Type Power Press Machine
The C Type Power Press Machine fits many tasks. It works for both small and large jobs.
Used for small parts and fast work
Good for regular sheet metal jobs
Used for heavy parts and thick sheets
Best for large and strong components
Industries Served
The C-Type Press is trusted across demanding industrial sectors worldwide
Need a High-Speed Press
for Your Production Line?
Tell us your required capacity, application, and production targets. Our engineering team will recommend the right C-Type configuration for your needs across the UAE. We respond within 24 hours.
Built for Reliability C Frame Hydraulic Press Advantages
The C Frame Hydraulic Press design is simple and strong. It gives easy access to work areas. It helps reduce time and effort. The system also lowers downtime. Many industries trust it for daily use. Today, C Type Hydraulic Power Press Manufacturers improve this design for better results.
Why Businesses Trust Trufmac Machines
Choosing the right brand is important. Trufmac offers quality and trust in India and the UAE. Every C Type Power Press Machine is built with care.
- Strong design and long life
- Custom machine options
- Fast service support
- Quality testing before delivery
- Fair pricing
Trufmac Global Pvt. Ltd. serves many industries. The company has strong engineering skills. Clients trust its machines for stable output.
Need a High-Speed Press for Your Production Line?
Tell us your needs. Share your job type and output goal. We will guide you. Our team will suggest the right C Type Power Press Machine. We also support buyers looking for C Type Hydraulic Power Press Machine Suppliers. Our solutions include Hydraulic Power Press C Type systems for better results.
Contact us today. You can also reach us on our contact number for quick help. Trufmac is ready to support your production needs.
